Outdoor Resort Igloo House Glamping Geodesic Dome Tent
Geodesic dome tent main framework is short Q235B steel tubes,with double side coated PVC cover and transparent PVC window;the fabric is UV-protection, waterproof and flame-retardant.It’s also modular type, so it is can be dismantled and installed easily.
Geo Dome Tent
Geodesic Dome Tent
Glamping Dome
Glamping Dome Tent
Geodesic dome tent size can be from 4 meters diameter to 40 meters diameter, there are also some optional accessories to decorate the tent for different application, such as the ventilation system, insulation film, skylight window,wooden floor etc. Also there are some versatile design,like transparent front,opaque PVC fabric, exchangeable clear PVC for skylight.Logo print or fully color printed fabric.
The durable, robust and reliable framework allows for the suspension of additional equipment such as lighting or sound systems. When combined with different structures the possibilities of arranging the event are simply endless.
With these advantages,it has a widely application,such as outdoor parties, exhibition,glamping, trade shows,temporary meeting,wedding hall,etc.
Our Geodesic Dome Tent Sample Video
Models & Sizes (Span width from 4M to 40M)
| Diameter(m) | Top Height(m) | Frame Strut(mm) | Floor Area(㎡) | Capacity (People sitting) | Capacity (People standing) |
|---|---|---|---|---|---|
| 4m | 2.5 | Φ26*1.5 | 12.57 | 2 | 2 |
| 6m | 3.5 | Φ26*1.5 | 28.26 | 10-15 | 25 |
| 8m | 4 | Φ26*1.5/Φ32*2 | 50.24 | 25-30 | 55 |
| 10m | 5 | Φ32*2 | 78.5 | 50-70 | 100 |
| 15m | 7.5 | Φ32*2 | 177 | 120-150 | 260 |
| 20m | 10 | Φ42*2 | 314 | 250-300 | 420 |
| 25m | 12.5 | Φ42*2 | 491 | 400-450 | 650 |
| 30m | 15 | Φ48*2.5 | 706.5 | 50-600 | 800 |
| 35m | 17 | Φ48*2.5 | 961 | 850-900 | 1100 |
| 40m | 18 | Φ60*3 | 1256 | 1000-1100 | 1350 |
Specification
-Flexible detaching and relocation
-Easy to assemble and disassemble, short construction period for puting into use
-Repeatedly built and used
-Low construction cost with no foundation treatment needed
-Equipped solution with security system, power supply, heating system, ventilation and other ancillary equipment.
-Convenient transportation and storage
| Frame material | Steel |
|---|---|
| Fabric cover | PVC-coated polyester textile; 100% waterproof;UV resistant, tear-resistant, self-cleaning ability, etc. |
| Cover | 850g/sqm white PVC/acrylic Fabric |
| Fabric color option | White, yellow, Green, Blue, transparent and customized |
| Connector | Strong hot-dip galvanized steel. |
| Allowed temperature condition | -32 degree Celsius +72 degree Celsius |
| Wind load | 80-100km/h |
| Snow load | 80kg/sqm (snow can’t stay if use big degree roof pitch design) |
| Other features | Easy to assemble and disassemble. No pole inside, 100% available interior space |
- PVC window sidewalls
- Anchoring
- Rain Gutter
- Lining and curtain
- Glass door units
- Hard walling system
- Glass walling system
- Transparent PVC cover and sidewall
- Flooring system
- Passenger door
- Manual/Automatic rolling door
- Sandwich panel wall
- Flooring system
- Weight plate
- Air conditioning
Furniture
Product Gallery
